Applications
This instrument is primarily used for the efficient homogenization and emulsification of two immiscible liquids, as well as the extraction of trace organic compounds, lipids, and organic solvent-soluble substances in water. It is widely used as a laboratory instrument in universities,environmental protection, health and epidemic prevention, chemical industry, water supply,and medical units.
Features
Operational mode allows for continuous operation for approximately 15 minutes. Equipped with a DC motor,which offers excellent performance, high speed,low heat generation, long lifespan, and lower energy consumption. Capable of homogenizing and mixing tissues of various animals and plants. Able to rupture cell membranes and separate them, as well as break DNA strands into small molecules at different speeds. Digital speed display for intuitive reading.
Specifications
| Speed Range | 2000~20000rpm |
| Motor Power | 200W |
| Processing Volume | 20-1200mL |
| Adjustment Method | Knob Infinitely Variable Speed Control |
| Protection Rating | IP20 |
| Maximum Viscosity | 5000mpas |
| Set 1: Small Capacity Blade | Diameter 12mm, Length 15cm, Processing Capacity:20-1000mL |
| Set 2: Large Capacity Blade | Diameter 18mm, Length 16cm, Processing Capacity:20-1200mL |
| Material of Contact Substance | Stainless Steel and Polytetrafluoroethylene (PTFE) |
| Power | 110-120V/60HZ, 220-240V/50-60Hz |
| Instrument Dimensions (Including Bracket) (LxWxH) | 360mm × 320mm × 600mm |
| Motor | Direct Current High-Speed Motor |
| Weight | 4Kg |
| Permissible Ambient Temperature and Humidity | 0-40℃, 85%RH |
Comparison of Effects
The high-speed homogenizing emulsifier uses an internal suction structure, providing high speed and efficient homogenization and emulsification of immiscible liquids.
