Floating piston design:
Smooth feel for liquid suction and discharge.
Suction: The piston is lifted upwards.
Discharge: The piston is pressed downwards.
Precise scale:
Digital window, gear slot design for more accurate liquid dispensing.
Safety shut-off valve:
Switch design to prevent accidental liquid dispensing, liquid waste, and leakage.
Scale adjustment knob:
The rotating button adjusts the range,making operation
Tube end safety cap:
Prevents residual liquid from flowing out.
Includes 5 types of bottle neck adapters, suitable for reagent bottles of different sizes in the laboratory.
Application
The simple bottle-top dispenser is widely used for routine liquid dispensing in fields such as chemistry,biology, pharmaceuticals, food, environmental monitoring, and scientific research education.
Features
Specifications
| Volume Range | Graduation (mL) | Test Volume (mL) | Systematic Error (±%) | Systematic Error (±μL) | Random Error (±%) | Random Error (±μL) |
|---|---|---|---|---|---|---|
| 1-5mL | 0.1 | 1 | 5 | 50 | 1 | 10 |
| 1-5mL | 0.1 | 2.5 | 1 | 25 | 0.2 | 5 |
| 1-5mL | 0.1 | 5 | 0.5 | 25 | 0.1 | 5 |
| 2-10mL | 0.2 | 2 | 5 | 100 | 1 | 20 |
| 2-10mL | 0.2 | 5 | 1 | 50 | 0.2 | 10 |
| 2-10mL | 0.2 | 10 | 0.5 | 50 | 0.1 | 10 |
| 5-30mL | 0.5 | 5 | 5 | 250 | 1 | 50 |
| 5-30mL | 0.5 | 15 | 1 | 150 | 0.2 | 30 |
| 5-30mL | 0.5 | 30 | 0.5 | 150 | 0.1 | 30 |
| 10-60mL | 1 | 10 | 5 | 500 | 1 | 100 |
| 10-60mL | 1 | 30 | 1 | 300 | 0.2 | 60 |
| 10-60mL | 1 | 60 | 0.5 | 300 | 0.1 | 60 |
